PAN 02
DI box active
$89.99
Backordered – More on the Way!
Product information "PAN 02"
Standard active DI box. Can be operated with 9 V batteries or 48 V phantom power. High-impedance input; higher output level than with a passive DI box. Active circuitry allows for high input impedance ( 1 meg. ohm) and higher input sensitivity (typical difference between in and out -4 dB). Maximum output impedance with phantom power operation +10 dB. Output: transformer balanced. The special "floating ground" circuitry enables ground lift even during phantom power operation. Metal case 110 x 73 x 42 mm.
| Input pad: | 0 / -30 dB |
|---|---|
| Cabinet surface: | Powder coated |
| Max. input level: | + 45 dBu |
| Output connectors: | XLR, 6.3 mm jack |
| Depth: | 2.87 in |
| Height: | 1.65 in |
| THRU outputs/channel: | 1 |
| Frequency response: | 10 - 20000 |
| Power supply: | +48 V phantom power, 9 V block |
| Transformer balanced: | Yes |
| Controls: | attenuator, ground lift |
| Product type: | DI boxes |
| Output impedance: | 600 |
| Max. output level: | + 10 dBu |
| Channels: | 1 |
| Cabinet material: | sheet steel |
| Width: | 4.33 in |
| Ratio: | 1 : 1 |
| Type: | active |
| Power consumption: | 3.8 mA (9V), 4 mA (48V) |
| Input connectors: | 6.3 mm jack |
| Input impedance: | (@ 60 Hz) 1 M |
| Inputs: | 1 |
| Number of outputs: | 1 |
