COMPACT BASE
Cable protector Base | black | light duty | height 3.7cm
$79.99
Backordered – More on the Way!
Product information "COMPACT BASE"
In combination with the optionally available 5-channel lower section, the DEFENDER® COMPACT cable protector is transformed into a very robust cable protector with a high load-bearing capacity that even allows trucks, forklift trucks and other vehicles to drive over it. With its ribbed anti-slip surface and integrated connectors in the bridge and base section, the DEFENDER COMPACT system with base section can also be laid as a stable, continuous line. Areas of application include construction sites, warehouses, shopping centres, trade fairs, exhibitions, carnivals and music events.
| Max. Passing speed: | 7 km/h |
|---|---|
| Maximum load (on 20 x 20 cm): | 2 t |
| Chemical resistance: | Oil, Petrol, Solvents (short-term contact) |
| Shape: | Round |
| Load per axle: | 4 t |
| Colour: | Black |
| Surface structure: | Ribbed |
| Material: | TPU (Thermoplastic polyurethane) |
| Hardness range (±4 Shore A): | 88 Shore A |
| Cable ducts size (W x H): | 28 cm x 23 cm - 28 cm x 30 cm |
|---|---|
| Quantity: | 5 |
| Duct length (effective length): | 31.69 in |
| Inflammability (UL 94): | V-2, HB |
|---|---|
| Fire protection class per DIN 4102-1: | B2 |
| Meets CP65: | 1 |
| Ambient temperature: | -30 - 60 °C |
| Meets TSCA: | 1 |
| Fire protection class per EN 13501-1: | E |
| Length: | 32.68 in |
|---|---|
| Weight: | 4.41 lbs |
| Width: | 9.13 in |
| Height: | 1.46 in |
| Certifications: | Germany: TÜV Süd |
|---|
Login
accessories
7 small cable ducts - the throw-over bridgeThe Defender® COMPACT cable protector is a lightweight, stable solution for protecting cables and preventing tripping hazards. With their ribbed anti-slip surface and integrated dovetail connectors, DEFENDER COMPACT throw-over bridges are suitable for pedestrian traffic in office buildings, shopping centres and conference rooms as well as at trade fairs and markets and for stage and studio use.Mark your Cable protectors! From an order quantity of just 30 units per model, you have the option of customising all DEFEBDER Cable protectors with your company logo. The corresponding format template is available in the download area above. Please contact us.
