Legend GB 128 B
12" Speaker 50 W 16 Ohms
Item no.: EGLB128B
Guarantee: 24 months
EAN: 4049521213298
Sliding scale: 1
Unit: Piece
Packaging unit: 1
Item highlights:
The Eminence Legend GB128 guitar speaker helps clean up your act. Cleaner British voiced tone with a full low end, warm, throaty mids and a very open top end. Turn up the volume and turn back the clock.
Specifications
Product type
Loudspeaker Chassis
Nominal Diameter
12 "
Nominal Diameter
304.8 mm
Voice Coil
1.75 "
Voice Coil
44 mm
Overall diameter
305.6 mm
Pitch Circle Diameter
294.4 mm
Cut- out Measurement
281.2 mm
Diameter of fixing holes
6.4 mm
Depth
129.5 mm
Nominal Impedance
16 Ohm(s)
Nominal Load Capacity
50 W
Sensitivity (1 W / 1 m)
101.3 dB
Frequency response
80 - 5100 Hz
Voice Coil Material
copper
Magnet
Ferrite
Depth of the magnetic gap
7.9 mm
Fs (Resonance Frequency)
86 Hz
Re (DC resistance)
6.37 Ohm(s)
Qms (mechanical quality)
19.54
Le (inductance of the voice coil)
0.64 mH
Qes (electrical quality)
0.67
Qts (overall quality)
0.65
Vas (equivalent volume)
43.9
Mms (moving mass)
28 g
BL (power factor)
12 T/m
Xmax (maximum displacement)
0.8 mm
Cms (elasticity of the suspension)
0.12 mm/N
Sd (membrane area)
506.7 cm²
Weight
4,58 kg
