CV-75 B
12" Speaker 75 W 16 Ohms
Item no.: ECV75B
Guarantee: 24 months
EAN: 4049521168826
Sliding scale: 1
Unit: Piece
Packaging unit: 1
Item highlights:
Over ten years in development, we've captured the epitome of British tone. Complete tonal balance - grunt and punch in the lows, warm/tailored mids, and nice, clear, open/airy highs.
Specifications
Product type
Loudspeaker Chassis
Type
Guitars
Nominal Diameter
12 Inch
Nominal Diameter
305 mm
Voice Coil
1.75 Inch
Voice Coil
44 mm
Overall diameter
309.1 mm
Pitch Circle Diameter
298.5 mm
Cut- out Measurement
282.7 mm
Diameter of fixing holes
6.1 mm
Depth
133.4
Nominal Impedance
16
Nominal Load Capacity
75 W
Sensitivity (1 W / 1 m)
102.2 dB
Frequency response
80 Hz - 5500 Hz
Voice Coil Material
copper
Magnet
Ferrite
Depth of the magnetic gap
8 mm
Fs (Resonance Frequency)
79 Hz
Re (DC resistance)
6.89 Ω
Qms (mechanical quality)
15.07
Le (inductance of the voice coil)
0.52 MH
Qes (electrical quality)
0.43
Qts (overall quality)
0.42
Vas (equivalent volume)
52.45
Mms (moving mass)
28 g
BL (power factor)
15 T/M
Xmax (maximum displacement)
1.23 mm
Cms (elasticity of the suspension)
0.14 MM/N
Sd (membrane area)
519.5 CM²
