PRO 15
Archive

PRO 15

15" PA Speaker passive

Item no.: LDPN1522

Guarantee: 24 months

EAN: 4049521042355

Sliding scale: 1

Unit: Piece

Packaging unit: 1

Series:PRO

Item highlights:

The LD Systems LDPN1522 is a passive bass reflex multifunctional loudspeaker equipped with a 15" FE speaker and a 1" compression driver.

This loudspeaker was designed for live applications, both as a full-range solution as well as in combination with a subwoofer. It has an output of 1200 W Peak and a high sound pressure level of 124 dB (max.) and impresses with rich bass response and an assertive midrange.

Additional highlights are the built-in rigging points, the 36 mm stand mount and the rugged overall design. Optional wall-mount brackets and monitor supports are available. The perfect PA solution for bands, mobile discos or permanent installation in medium-sized clubs and other function rooms.

Specifications

Product type
PA loudspeaker
Type
Passive
Low/mid Woofer dimensions
15 "
Woofer dimensions (mm)
381 mm
Woofer magnet
Neodymium
Woofer brand
Custom-made
HF driver dimensions
1 "
HF driver dimention (mm)
25 mm
HF driver magnet
Ferrite
HF driver brand
Custom-made
Dispersion (H x V)
90 x 40 °
Load rating (RMS)
300 W
Peak power
1200 W
Frequency response
55 - 18.000
SPL (1W/1m)
99 dB
Max. SPL
124 dB
Impedance
8 Ohm(s)
Protection circuits
HF Driver
Loudspeaker inputs
1
Speaker input connections
Speakon compatible
Loudspeaker outputs
1
Speaker output connections
Speakon compatible
Cabinet material
Polypropylene
Cabinet construction
Bass Reflex
Width
450 mm
Height
685 mm
Depth
380 mm
Features
Speaker Pole Mount (36 mm)
Weight
20,15 kg
