5530 NDH
1" High-Frequency Driver 16 Ohms 80 W
Item no.: BMS5530NDH
Guarantee: 24 months
EAN: 4049521466038
Sliding scale: 12
Unit: Piece
Packaging unit: 12
Item highlights:
- Unique Patented Design
- Neodymium Magnet Assembly
- 113 dB sensitivity 1 W / 1 m
- 1 kHz Crossover
- Extended high frequency response up to 20 kHz
- Small size and low weight
- 44.4 mm sandwich in- and outside voice coil
Specifications
Product type
High-frequency Drivers
Nominal Diameter
1 "
Nominal Diameter
25.4 mm
Voice Coil
1.75 "
Voice Coil
44.4 mm
Overall diameter
72 mm
Depth
35 mm
Nominal Impedance
16 Ohm(s)
Nominal Load Capacity
80 W
maximum rated load
450 W
Frequency response
500 - 20000 Hz
recommended crossover frequency
1000 Hz
Voice Coil Carrier
Kapton
Diaphragm material
Polyester
Magnet
Neodymium
Recommended horn
BMS2119, BMS2193, FPSTH100
Mounting holes
3
Diameter of fixing holes
M5
Pitch Circle Diameter (bolt on)
57.15 mm
Weight
0,5333 kg
Description
5530 NDH
The 5530 NDH is an ultra-compact 1“ high output compressiondriver with unique output to size ratio.
