4552 NDH
1" Neodymium High-Frequency Driver 80 W 16 Ohms
Item no.: BMS4552NDH
Guarantee: 24 months
EAN: 4049521023286
Sliding scale: 12
Unit: Piece
Packaging unit: 12
Item highlights:
1" Neodymium high-frequency Driver 80 W 16 Ohm
Specifications
Product type
High-frequency Drivers
Nominal Diameter
1 "
Nominal Diameter
25.4 mm
Voice Coil
1.75 "
Voice Coil
44.4 mm
Overall diameter
85 ± 0.1 mm
Pitch Circle Diameter
76.2 mm
Depth
36 mm
Nominal Impedance
16 Ohm(s)
Nominal Load Capacity
80 W
maximum rated load
450 W
Sensitivity (horn 1 W / 1 m)
113
Frequency response
500 - 20000 Hz
recommended crossover frequency
1000 Hz
Voice Coil Carrier
Kapton
Diaphragm material
Polyester
Magnet
Neodymium
Mounting holes
2
Diameter of fixing holes
M5
Pitch Circle Diameter (bolt on)
76.2 mm
Weight
0,816 kg
