U308 BP

U308 BP

Bodypack transmitter

Item no.: LDU308BP

Guarantee: 24 months

EAN: 4049521336409

Sliding scale: 1

Unit: Piece

Packaging unit: 100

Series:U300

Versions:

Item highlights:

Operating in the 823 - 832 MHz, 863 - 865 MHz band, this U300 Series bodypack transmitter features a miniature XLR input with 3-position level selector to accommodate microphones as well as active and passive instrument pickups. It has an output power of 10 mW and 25 Hz - 16 kHz frequency response to handle 5-string bass guitars with a low B string. The U308 BP provides over 10 hours of continuous operation on two AA batteries, easy IR syncing with the U308 receiver and pilot tone transmission to eliminate RF interference. The bodypack's on/off switch includes a convenient standby position for temporary muting.

Specifications

Product type
Wireless Microphone System Accessories
Type
Bodypack
Transmission frequency range
823 - 832 MHz, 863 - 865 MHz
Channels
12
Groups
1
Inputs
Mini-XLR (Phantom Powered Low-Z / High-Z Instrument)
Frequency response
25 - 16,000
Signal-to-noise ratio
104 dB
Rated HF output power
10 mW
Controls
Gain (3-way switch), Power On/Off
Indicators
ASC IR Sync (Green/Amber Blinking LED), Battery (low battery: red), Power LED (Power ON: green)
Power supply
2 x AA batteries
Operating time
>10 h
Width
65 mm
Height
91 mm
Depth
25 mm
Weight
0,085 kg
Other features
Belt clip, IR frequency synchronisation, Pilot tone
