DALIMa 14Q DANTE

VIDEO

DALIMa 14Q DANTE

DALIMa 5Q 4 channel amplifier + DANTE

Item no.: RAMDALIMA14QD

Guarantee: 60 months

EAN: 4049521951510

Sliding scale: 1

Unit: Piece

Packaging unit: 1

Series:DALIM

Versions:

Questions about the item?

Item highlights:

High efficiency class D topology
Universal power supply with PFC
Up to 20000 W in 4 channels
8, 4 and 2 Ohm low impedance operation
100, 70, 50 V high impedance modes
RAM Audio advanced Power Control Management (PCMTM)
Industry standard Neutrik® XLR and Speakon® connectors
Neutrik® PowerCon mains connector (32A version in 14Q and 20Q models)
Removable dust filter foam
Up-side-down design to avoid fan dust accumulation
Temperature controlled, front to back cooling fan
Optional GPIO module, except for 14Q and 20Q models
Optional DANTE input

Specifications

Channels

4

Total output power

14000 W

Rated ouput power @ 2 Ohms (all channels driven)

4 x 3500 W

Rated ouput power @ 2 Ohms (single channel)

1 x 3500 W

Rated ouput power @ 2.67 Ohms (all channels driven)

4 x 3500 W

Rated ouput power @ 2.67 Ohms (single channel)

1 x 4700 W

Rated ouput power @ 4 Ohms (all channels driven)

4 x 3500 W

Rated ouput power @ 4 Ohms (single channel)

1 x 3750 W

Rated ouput power @ 8 Ohms (all channels driven)

4 x 1800 W

Rated ouput power @ 8 Ohms (single channel)

1 x 1900 W

Rated ouput power (8 Ohms, bridged)

2 x 7000 W

High Z 70Vrms / 100Vpeak

1 x 4200 W, 4 x 3500 W

High Z 100Vrms / 140Vpeak

1 x 2950 W, 4 x 2950 W

Max output voltage

189 Vpeak

Max. output current

59 Apeak

Total Harmonic Distortion (THD)

< 0.05 %

Crosstalk (20Hz - 1kHz)

> 70 dB

Voltage gain

26 dB to 44 dB

SNR

113 dBA

Operating voltage

90 V AC - 265 V AC, 50 - 60 Hz

1/8 rated power (@230V/4 ohm)

10 A / 2288 W

1/8 rated power (@120V/4 ohm)

19.2 A / 2288 W

Idle

1 A / 112 W

Thermal dissipation

1834 BTU / h

Protection circuits

DC, on/off transients, ICL™, Short circuit, Open or mismatched loads, PCM ™, soft start, mute when turning on, thermal overload, power supply overload

Width

483 mm

Height

89 mm

Depth

355 mm

Weight

9 kg

Description

DALIMa 14Q DANTE

DALIMa Series are 4-channels high power level amplifiers designed to the tough requirements of the touring market. It is remarkable their high efficiency.

These amplifiers are based on their predecessors DALIM amps, where DSP has been removed; for these applications where external DSPs are used, so you do not have to pay extra money for it.

In the design it has been implemented the advanced RAM Audio Power Control Management to configure through the DSP how to sharing the power between the channels according to the user needs, having the possibility to obtain in just one channel the maximum power.

Optional GPIO and DANTE inputs are available for DALIMa amplifiers.
